EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection

EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection

EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection

Brand Name: EVERGEAR
Model Number: EFF37~EFF157
MOQ: 1
Price: $59
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 99999999
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001,ISO14001,ISO24001,CE
Power Range:
0.18KW-200KW
Ratio:
4.81-259.74
Output Speed:
0.12-310rpm
Output Torque:
200N.m-18000N.m
Input  Speed:
500rpm,750rpm,1000rpm,1500rpm,1800rpm
Output Shaft Diameter:
25mm-120mm
Mounting Way:
Foot Mounted, Shaft Mounted, Flange Mounted,shrink Disc Mounted,Buffer Rubber Mount,Backstop Mount
Input Way:
Solid Shaft Input, Hand Wheel Input, AC Motor Input, Servo Motor Input
Output Way:
Solid Shaft , Two Side Output Shaft ,hollow Shaft, Shrink Disc Etc
Weight:
19KGS-679KGS
Ambient Temperature:
-15.00 [°C] ~ +40 [°C]
Direction Of Rotation Of Gear Output Shaft:
CW Rotation Or CCW
Corrosion Protection:
Conservation Acc. To Norm C1,C2,C3,C4,C5
Coating System:
Standard Coating, Finishing Coat, For All Climatic Zones
Color:
Blue RAL5010 /Grey RAL7031 Or Any Color You Need
Packaging Details:
Export Strong wooden case and pallet
Highlight:

0.18KW-200KW Power Range Parallel Shaft Gear Motor

,

200N.m-18000N.m Output Torque Helical Gearbox

,

C1-C5 Corrosion Protection Speed Reducer

Product Description
EFF Series Parallel Shaft Mechanical Transmission Helical Gearbox Motor Gear Speed Reducer
The EF Series parallel shaft helical gear motor delivers reliable power transmission with high efficiency and durability for demanding industrial applications.
Available Models
EFF37, EFF47, EFF57, EFF67, EFF77, EFF87, EFF97, EFF107, EFF127, EFF157
Technical Specifications
Smaller Frame Sizes
Model EFF 37 EFF 47 EFF 57 EFF 67 EFF 77
Structure Form EF/EFAB/EFF/EFA/EFAF/EFAZ
Input Power (KW) 0.18-3 0.18-3 0.18-5.5 0.18-5.5 0.18-11
Ratio 4.81-111.63 6.85-148.5 4.92-199.7 5.07-195.1 5.7-286.59
Permissible Torque (Nm) 200 400 600 820 1500
Weight (KGS) 19 25 29 35 62.5
Larger Frame Sizes
Model EFF 87 EFF 97 EFF 107 EFF 127 EFF 157
Structure Form EF/EFAB/EFF/EFA/EFAF/EFAZ
Input Power (KW) 0.37-22 0.55-30 0.75-45 4-90 5.5-200
Ratio 5.31-268.37 4.36-227.85 5.5-248.6 5.11-172.24 11.92-259.74
Permissible Torque (Nm) 3000 4300 7840 12000 18000
Weight (KGS) 109 182 259 431 679
Product Documentation
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 0
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 1
Installation View
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 2
Dimensional Drawing
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 3
Parallel Shaft Configuration
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 4
Cross-Section View
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 5
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 6
Performance Chart
EFF Series Parallel Shaft Gear Motor with 0.18KW-200KW Power Range and 200N.m-18000N.m Output Torque Featuring C1-C5 Corrosion Protection 7
Technical Specifications
For detailed technical data and custom specifications, please contact our engineering team for professional assistance.
